Motor Control Centers (MCC)
Project-configured motor control assemblies for pumps, utilities and industrial process systems. Configure motor feeders, starting methods, protection and PLC interfaces according to project requirements.
Motor feedersIsolation / protection / control
Starter optionsDOL / star-delta / soft starter / VFD
Control interfaceLocal / remote / PLC
Project inputMotor list / SLD / control sequence
Choose configuration options below, or contact us directly.
01 Technical data
Configuration & project information
Choose the arrangement below and add the details you have.
Information to provide
- Motor list
- Motor quantities, power, current, operating duty and starting constraints.
- Single-line diagram
- Supply arrangement and motor feeder connections.
- Control sequence
- Operating modes, interlocks, alarms and control interfaces.
02 Application engineering
Applications
Pumping and water treatment
Pump and blower feeders group motor starting, overload protection and operating status in one MCC. Duty/standby changeover, level or pressure signals and process interlocks define the control interfaces. Motor data, starting frequency and the process requirement for speed control guide the choice of direct starting, soft starters or drives.
Production and material handling
Conveyors, mixers and compressors need motor feeders matched to their starting duty and operating sequence. The motor list defines ratings and feeder quantities; load characteristics determine starting methods and protection. Process permissives, fault feedback and local isolation must be coordinated with the line control system and maintenance procedures.
Ventilation and building services
Fans, circulation pumps and other building services can be grouped in an MCC with local and remote control. Operating schedules, speed-control requirements and building-management signals define the interfaces. The design must distinguish ordinary process commands from safety-related shutdown functions and establish how faults and running status are reported.
03 Define your configuration
Select your configuration
All fields are optional. Choose one or more options as indicated; use Other for a custom requirement.
Starter requirement
Select all that apply.
Control mode
Select one.
Motor duty
Select one.
Project information
Select all that apply.
Additional requirements
Supply voltage requested
Enter details
Motor power & quantity
Enter details
Enclosure requirement
Enter details
Component preference
Enter details
Supply frequency
Enter details
Current requirement (A)
Enter details
Electrical values entered here are requested requirements. Equipment ratings must match the selected model and its technical datasheet.
Hardware, software, source files and commissioning are separate scope items.
04 Construction and options
Construction & configuration options
05 Applicable standards and requirements
Standards & engineering
- Project specification
- Provide the applicable standard editions, destination requirements and tender specification.
- Rating schedule
- Keep the electrical ratings and installation limits linked to the selected model.
- Verification documents
- Identify the required inspection records, test reports and acceptance criteria.
- Supply scope
- Define motor feeders, selected starters and control wiring in the project scope. PLC / SCADA programming, source files and on-site commissioning require separate confirmation; they are not included by default.
06 Manufacturing & Projects
From Production to Projects
Project documentation
Project Documents
Documents you can send
Send existing drawings or lists. You can start an inquiry without a complete document package.
- Motor list
- Single-line diagram
- Control sequence and interlock list
- Power and control wiring drawings
Documents to request
Ask for the following documents for the selected equipment. Document availability and delivery stage are agreed with the quotation.
- Configuration and component schedule
- Arrangement and power / control wiring drawings
- Model datasheets and applicable verification records
07 Decision support
Frequently asked questions
Can one MCC use different starting methods?
Yes. Select DOL, star-delta, soft starter and VFD together, then assign the required method to each motor in the motor list.
How do I choose between a soft starter and a VFD?
State whether the motor needs controlled acceleration only or speed control during operation. Include motor power, load characteristics and starting constraints.
Does a PLC interface include PLC programming?
A PLC interface defines the signal connection. PLC programming, SCADA integration, source files and commissioning are separate scope items.
